Sensors and electronics for the construction of scales

AED - Digital electronics

AED electronics convert your analog sensors into a digital system.

C16A

Accuracy classes: D1, C3, C4 according to OIML R60, capacities 20t-400t , material stainless steel, IP68, ATEX, laser welded stainless steel sensor body, self ...

C16i

C16i digital load cell: accurate weighing up to 60 tonnes With the C16i digital load cell, heavy loads up to 60 tonnes can be accurately weighed with class ...

C16M Built-in weighing blocks up to 200t

C16M: Built-in weighing module not only for tanks from 20t to 200t Whether it is tanks of the construction industry, coal storage tanks or tanks for liquids and gases, the weighing ...

C2 (kg/t)

Stainless steel pressure load cell. Accuracy classes: 0.1% or 0.2% (for 50kg capacity), 50kg - 50t capacity. Material stainless steel, protection IP67, ATEX.

C2A

Stainless steel pressure load cell. Accuracy classes D1, C3, C4, Capacities 1t-10t. Material stainless steel, protection IP67, ATEX.

DSE

DSE-HIE: Future-proof and EHEDG-compliant sensor electronics The innovative digital sensor electronics (DSE) is ideal for use in ...

ELCB2 HS

Accuracy class: 1% of the sensor range. Capacities 110kg - 1.76t. Material stainless steel, IP68 and IP69K protection.

FIT5A

Digital single point sensor for dosing/filling - RS485, CANOpen, DeviceNet, capacities 5kg - 50kg, C3 according to OIML R60, platform up to 400x400mm, stainless steel, housing ...

FIT5X - digital load cell up to 20kg

Digital load cells FIT5X: Not only for rotary filling machines The FIT5X strain gauge load cell is equipped with advanced electronics and works both ...

FIT7A

Digital single point encoder for checkweighers - RS485, CANOpen, DeviceNet, capacities 3kg - 75kg, C3 and C4 according to OIML R60, platform up to 600x500mm, stainless steel, ...

HLC

Accuracy classes D1, C3, some variants also C4, C6, capacities 110kg - 10t, material stainless steel, protection IP68, ATEX.

LCMC - weighing chain

Load Cell Measurement Chain (LCMC) - Intelligent Customizable Weighing Chain Create a customized LCMC digital weighing chain with optional com ...

PAD

PAD: single channel amplifier for digitizing analog sensors! The PAD electronics digitizes the output of passive strain gauge load cells to p ...

PW10A

Accuracy classes C3, C3MR according to OIML R60, platform up to 600x500mm, capacities 50kg - 300kg, material aluminium, protection IP67, ATEX.

PW12C

Accuracy classes C3MR according to OIML R60, platform up to 800x800mm, capacities 50kg - 750kg, material aluminium, IP67, ATEX.

PW15AH

Accuracy classes C3MR according to OIML R60, platform up to 500x400mm, capacities 10kg - 100kg, material stainless steel, protection IP68/IP69K.

PW15B

Accuracy classes C3MR according to OIML R60, platform up to 500x400mm, capacities 7,5kg - 200kg, material stainless steel, IP67, ATEX.

PW15PH

Accuracy classes: C3MR according to OIML R60, platform up to 500x400mm, capacities 10kg - 100kg, stainless steel material, protection IP67, IP68/IP69K, hygienic plants.

PW16A

Accuracy classes C3MR according to OIML R60, platform up to 600x600mm, capacities 30kg - 660kg, material aluminium, IP67, ATEX.

PW22

Accuracy classes C3MR according to OIML R60, platform up to 400x400mm, capacities 6kg - 90kg, material aluminium, IP67, ATEX. Optimized for dynamic weighing.

PW25/PW25P

Accuracy classes: C3MR according to OIML R60, platform up to 400x400mm, capacities 10kg, 20kg, stainless steel material, protection IP67, IP68/IP69K, hygienic plants.

PW27A / PW27AP

PW27A: For hygienic weighing up to 20 kg With the load cells of the PW27A product series, companies producing and filling food products are well ...

PW28

Single point sensors PW28 for accurate weighing of weights from 5 kg to 75 kg Thanks to a minimum verification interval ratio of up to 20,000, the single point sensor corresponds ...

PW29/PW29P

Accuracy classes: C3MR according to OIML R60, platform up to 800x800mm, capacities 100kg, 250kg, 500kg, 750kg, 1000kg, material stainless steel, protection IP67, IP68/IP69K, hermetic ...

PW2C

Accuracy classes C3MR, C6, C6MR according to OIML R60, platform up to 380x380mm, capacities 7,2kg - 72kg, material aluminium, IP67 protection. Optimization for static weights ...

PW2D

Accuracy classes C3MR according to OIML R60, platform up to 380x380mm, capacities 7,2kg - 72kg, material aluminium, IP67 protection. Optimized for dynamic weighing.

PW37P

PW37P: Hygienic weighing up to 200 kg The PW37P precision single point load cell is ideal for the needs of the food industry. Its EHEDG certification from ...

PW4M

Accuracy class C3 according to OIML R60, platform up to 200x200mm, capacities 0,3kg - 3kg, material aluminium, protection IP65.

PW4M...OP

The PW4M...OP single point encoder is designed for low weight, with eccentricity compensation up to a platform size of 200x200mm and mechanical protection. S ...

PW6C

Accuracy classes C3MR, C6 according to OIML R60, platform up to 300x300mm, capacities 3kg - 40kg, material aluminium, protection IP67. Optimized for static weighing.

PW6D

Accuracy classes C3MR according to OIML R60, platform up to 300x300mm, capacities 3kg - 40kg, material aluminium, IP67 protection. Optimized for dynamic weighing.

PWSE

Accuracy classes C3MR according to OIML R60, platform up to 800x800mm, capacities 100kg - 750kg, material stainless steel, IP67 protection.

RSCC

Tacho load cell, accuracy class: C3. Capacities 50kg - 5t. Material stainless steel, protection IP68, ATEX.

RTN

Accuracy class C3, capacities 1t-470t, material stainless steel, hermetically sealed construction, IP68 protection, strain gauge full bridge 2.85mV/V, high ...

SP4M

Accuracy classes C3MR, C6MR according to OIML R60, platform up to 600x600mm according to capacity, capacities 1kg - 200kg, material aluminium, IP67, ATEX.

SP8

Single pointsensor SP8: Compact and cost-effective solution for combined scales with multiple heads The SP8 load cell has been optimized for use in ...

Shielded cables CABA1, CABA2, CABE2

Shielded cables for sensors, scales and strain gauges.

U2A

Tacho load cell, accuracy classes: 0.2, 0.1, D1. Capacities 50kg - 20t. Material stainless steel, protection IP67, ATEX.

Weighing module HLC/M (HLCM)

HBM supplies HLC/M weighing modules (also called HLCM) in capacities of 220kg, 550kg, 1.1t, 1.76t, 2.0t, 2.2t and 4.4t. The HLC/M built-in blocks are ...

RTN/M weighing module

RTN/M: Weighing module for RTN force gauges with ranges from 1t to 33t The RTN weighing module is designed to be easy to assemble, reducing assembly time and cost ...

Weighing module Z6M/Z6AM

Z6M and Z6AM weighing modules for accurate weighing up to 500 kg The Z6M and Z6AM weighing modules are supplied with high quality Z6F HBM force gauges and allow very high ...

VKK - junction box

The VKK1-4 / VKK1R-4 junction box allows the parallel connection of two to four load cells, the VKK2-8 / VKK2R-8 junction box allows the connection of ...

Calculations for scales with multiple sensors

WE2107

WE2107: the reliable weighing indicator for monitoring and controlling your weighing processes. It does not matter whether it is static or dynamic processes ...

WTX110-A

WTX110-A: Indicator for connecting analogue sensors. The rugged IP69K commercially approved weighing indicator is the best choice for displaying ...

WTX110-D

WTX110-D: Indicator for connecting digital sensors. The rugged IP69K commercially approved weighing indicator is the best choice for displaying ...

WTX120

WTX120: Industrial commercially approved weighing processor. With the new WTX120 industrial indicator, any analog strain gauge can be ...
